FB 82 GCr15 One Way Sprag 750 Nm Over Running Clutch

Ask Lasest Price
Brand Name :	SUMA
Model Number :	FB82
Certification :	ISO SGS
Price :	USD80-USD120 PER PIECE
Payment Terms :	L/C, D/A, D/P, T/T, Western Union,Paypal
Supply Ability :	1000PCS Per Month
Delivery Time :	7-15 Days

Add to Cart

Product Details
Company Profile

FB 82 GCr15 One Way Sprag 750 Nm Over Running Clutch

FB 82 GCr15 One Way Sprag 750 Nm Over Running Clutch

Features

Complete Freewheels FB are sealed sprag freewheels with ball bearings. They are supplied oil-filled and ready for installation.The freewheels FB are used as:

➧ Backstops

➧ Overrunning Clutches

➧ Indexing Freewheels

In addition to the standard type, four other types are available for extended service life and indexing accuracy.

Nominal torques up to 160 000 Nm.Bores up to 300 mm. Many standard bores are available.

Dimensions and Capacities

FB 82 GCr15 One Way Sprag 750 Nm Over Running Clutch

Fre ewh eel Size	Ty pe	Nom inal tor que MN Nm	M Inner ring freew heels/ over runs min-1	ax. speed Outer ring freew heels/ over runs min-1	Ty pe	Nom inal tor que MN Nm	Max. speed Inner ring freew heels/ over runs min-1	Outer ring freew heels/ over runs min-1	Ty pe	Nom inal tor que MN Nm	Sprag lift- off at inn er ring spe ed min-1	Max. speed Inner ring freew heels/ over runs min-1	Ou ter ring dri ves min-1	Ty pe	Nom inal tor que MN Nm	Sprag lift-off at outer ring speed min-1	Max. speed Outer ring freew heels/ over runs min-1	Inner ring driv es min-1	Ty pe	Nom inal tor que MN Nm
FB 24	CF	45	4 800	5 500	CFT	45	4 800	5 500											CFP	19
FB 29	CF	80	3 500	4 000	CFT	80	3 500	4 000											CFP	31
FB 37	SF	200	2 500	2 600	SFT	200	2 500	2 600						CZ	110	850	3 000	340	SFP	120
FB 44	SF	320	1 900	2 200	SFT	320	1 900	2 200	DX	130	860	1 900	344	CZ	180	800	2 600	320	SFP	180
FB 57	SF	630	1 400	1 750	SFT	630	1 400	1 750	DX	460	750	1 400	300	LZ	430	1 400	2 100	560	SFP	310
FB72	SF	1 250	1 120	1 600	SFT	1 250	1 120	1 600	DX	720	700	1 150	280	LZ	760	1 220	1 800	488	SFP	630
FB82	SF	1 800	1 025	1 450	SFT	1 800	1 025	1 450	DX	1 000	670	1 050	268	SFZ	1 700	1 450	1 600	580	SFP	750
FB 107	SF	2 500	880	1 250	SFT	2 500	880	1 250	DX	1 500	610	900	244	SFZ	2 500	1 300	1 350	520	SFP	1 250
FB 127	SF	5 000	800	1 150	SFT	5 000	800	1 150	SX	3 400	380	800	152	SFZ	5 000	1 200	1 200	480	SFP	3 100
FB 140	SF	10 000	750	1 100	SFT	10 000	750	1 100	SX	7 500	320	750	128	SFZ	10 000	950	1 150	380	SFP	6 300
FB 200	SF	20 000	630	900	SFT	20 000	630	900	SX	23 000	240	630	96	SFZ	20 000	680	900	272	SFP	12 500
FB 270	SF	40 000	510	750	SFT	40 000	510	750	UX	40 000	210	510	84	SFZ	37 500	600	750	240	SFP	25 000
FB 340	SF	80 000	460	630	SFT	80 000	460	630
FB 440	SF	160 000	400	550	SFT	160 000	400	550

The maximum transmissible torque is 2 times the specified nominal torque. See page 14 for determination of selection torque.

Freewheel Size	mm	mm	Bore Standard mm	red mm	mm	max. mm	D mm	F mm	G**	H mm		L mm	T mm	Z**		Weight kg
FB24	12	14*				14*	62	1,0	M 5		8	50	51		3	0,9
FB 29	15	17*				17*	68	1,0	M 5		8	52	56		3	1,1
FB37	14	16	18	20	22*	22*	75	0,5	M 6		10	48	65		4	1,3
FB44	20	22	25*			25*	90	0,5	M 6		10	50	75		6	1,9
FB57	25	28	30	32*		32*	100	0,5	M 8		12	65	88		6	2,8
FB72	35	38	40	42*		42*	125	1,0	M 8		12	74	108		12	5,0
FB82	35	40	45	50*		50*	135	2,0	M 10		16	75	115		12	5,8
FB107	50	55	60	65*		65*	170	2,5	M 10		16	90	150		10	11,0
FB127	50	60	70	75*		75*	200	3,0	M 12		18	112	180		12	19,0
FB140	65	75	80	90		95*	250	5,0	M 16		25	150	225		12	42,0
FB200	110	120				120	300	5,0	M 16		25	160	270		16	62,0
FB270	140					150	400	6,0	M 20		30	212	360		18	150,0
FB340	180					240	500	7,5	M 20		35	265	450		24	275,0
FB440	220					300	630	7,5	M 30		40	315	560		24	510,0

Keyway according to DIN 6885, page 1 • Tolerance of keyway width JS10.

* Keyway according to DIN 6885, page 3 • Tolerance of keyway width JS10.

** Z = Number of tapped holes G on pitch circle T.

Mounting and Coupling

Mounting

The customer attachment part is on the exter-nal diameter D and then bolted on to the face.The tolerance of the shaft must be ISO h6 or j6 and the tolerance of the pilot diameter D of the attachment part must be ISO H7 or J7.

Example for ordering

Freewheel size FB 72, type with sprag lift-off Z and 38 mm bore: • FB 72 LZ, d = 38 mm

When ordering freewheel size FB 340 and FB440, please also specify the freewheeling direction of the inner ring when viewed in direction X: • counterclockwise free or • clockwise free
