BREU30(K)-C Freewheel Cam Clutch Bearing With Grease

Ask Lasest Price
Brand Name :	SUMA
Model Number :	BREU30(K)-C
Certification :	ISO SGS
Price :	USD270-USD285 PER PIECE
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, Paypal
Supply Ability :	1000PCS Per Month
Delivery Time :	3-7 Days

Add to Cart

Product Details
Company Profile

BREU30(K)-C Freewheel Cam Clutch Bearing With Grease

BREU30(K)-C Freewheel Cam Clutch Bearing With Grease

Lubrication

BREU series Cam Clutches need periodic maintenance and lubrication to both bearing to provide maximum

performance throughout their service life. Lack of prescribed maintenance and lubrication will shorten the

Service life of Cam Clutch and may cause unnecessary mechanical damage.

Dimensions and Capacities

Model	BoreSize	Keyway	A	B	C	D	E	F	G	H	I	J	S	Weight
Model	H7	InnerRace			h7									kg
BREU30(K)-C	30	8×3.3	109.9	137	100	73	28	19.3	5.9	62.5	76	8.7	9.7	5.9
BREU35(K)-C	35	10×3.3	127.7	152	110	83	40	28.3	8.7	63.5	79	11.7	11.5	8.5
BREU40(K)-C	40	12×3.3	132.7	164	125	83	40	28.3	6.7	68.5	86	11.7	11.5	10.5
BREU45(K)-C	45	14×3.8	132.7	176	130	83	40	28.3	6.7	68.5	86	11.7	11.5	11.2
BREU50(K)-C	50	14×3.8	142.2	200	150	83	40	28.3	8.2	78	94	11.7	11.5	15.6
BREU55(K)-C	55	16×4.3	159.8	219	160	107	45	30.4	10.8	84	104	14.6	15.2	21.8
BREU60(K)-C	60	18×4.4	176.8	235	170	107	45	30.4	11.8	101	120	14.6	15.2	26.4
BREU70(K)-C	70	20×4.9	189.3	251	190	107	45	30.4	10.3	113.5	134	14.6	15.2	33
BREU80(K)-C	80	22×5.4	196.8	267	210	107	45	30.4	7.8	121	144	14.6	15.2	41

1. BREU-(K) C series Cam Clutch couplings make use of BREU series Cam Clutch and CR type couplingsInstallation and Usage

without cover.

2. Mount the clutch loosely on the high-speed shaft at first.

3. Accurately align both sprockets by checking with a straight edge on the teeth of both sprockets.

4. Check whether the clearance(S) between the two sprockets is correct, then wrap the chain around the

sprockets.

5. Specify right hand (RH) or left hand (LH) as inner race overrunning direction from the view of cam clutch side

(*) when ordering. See the above drawing.

6. The same lubrication as for Tsubaki roller chain is necessary for the coupling chain.

7. Ensure that the chain is properly closed with a connecting link and that the closed of the spring clip is installed

in the same direction as the rotation of the outer race.

Recommended Grease

Brand	Ambient Temperature
Brand	–5°C ~ +40°C	–40°C ~ +40°C
Esso	—	Beacon 325
Mobil	—	Mobil temp SHC100
Shell	Alvania Grease S2	Alvania Grease RA
BP	Energrease LS2	Enargrease LT2
TOTAL	Multis 2	Aerogrease 22

Note: Do not use Grease that contains EP additives.

E1~E7 options are supplied with bolts for installation, and the grease nipple.

Maintenance

BREU series Cam Clutches are pre-greased at the factory and should be re-greased every three months for both bearings after installation. Follow the procedure below.

1. Remove the set screw at the flange, torque arm or cover.

2. Inject equal amounts of grease into the bearing from the grease nipple. Refer to the grease volume table for the correct amount.

3. Run the Cam Clutch disengaged for from 20 to 30 minutes with the set screw removed. Excess of grease in the clutch area will flow out of the tapped holes. Be careful to avoid over greasing. Too much grease in the

clutch will cause it to run hot, interfere with the clutch action, and may lead to mechanical damage.

4. Wipe off excess of grease and re-install the set screw.
